We take the performance of your
embedded systems to a new level
PROVEN, RELIABLE & VERSATILE
Our sysWORXX ECUcore-AM62x is a proven and modern technology platform. Based on this module, we can adapt your individual requirements and application cost-effectively. Our solution offers you decisive advantages in terms of both time-to-market and design-to-cost.
Possible applications:
IoT/edge controller
IPC
PLC
HMI
gateway
Do you already know our sysWORXX Pi-AM62x?
It offers you the opportunity to test the interaction between hardware and software and to validate the planned system concept in advance.
To the sysWORXX Pi-AM62x
-
Features & Details...
n Core
CPU
TI Sitara™ AM623 up to Quad-Core Cortex™-A53 @ 1.4 GHz, optionally with 3D Graphics Processing Unit
Real-time Co-Pro
Cortex™-M4F @ 400 MHz
RAM
1 GiB DDR4 (max. 8GiB)
eMMC
8 GiB
RTC
on-board
Boot Mode
SD Card / eMMC
n Connectivity
ETH
2 (1Gbps, each with its own MAC address)
WiFi
802.11 a/b/g/n/ac
Bluetooth
5.2
CAN
2 (CAN-FD)
SIO
4 (2 of which with RTS/CTS hardware handshake)
USB
1 Host (USB 2.0 high-speed),
1 device (USB 2.0 high-speed)
Display
1 OLDI (Open LVDS Display Interface)
SD Card
1
SoM connector on base board
DIMM socket with 204 pins
n I/O interfaces
SPI
2
I2C
1
GPIO
41
A/B Encoder / Highspeed Counter
1
PWM
2
Analog inputs
4 (12Bit, optional 16Bit)
-
Software & Programming...
- Ready-to-use: Software development platform adapted to your requirements
- Yocto BSP or Debian/GNU Linux
- Docker-based build environment
- Base project in the form of a git repository
- Specific devicetree for your solution
- Secure OTA updates based on RAUC (Yocto)
- Support for setting up Secure Boot
- and much more.
- Use the programming language/environment of your choice
- Programmable in C/C++, Rust, Python and many more.
- Node-RED
- IEC 61131-3
- Consulting and workshops:
- Conceptual design of your product-specific Linux distribution
- Dealing with the respective build environment
- Development and integration of your application
We support you in every step of your development!
-
Ordering information...
Your contact:
Your SYS TEC electronic sales team
